Steam Accessories
Pressure Gauge (Analog Dial)
Industrial-grade glycerin-filled analog pressure gauge with white dial face and stainless steel case. Features dual scale markings (0–16 bar and 0–200 psi) with bottom-mounted stem connection for boiler and steam system monitoring.
- Glycerin damping reduces vibration
- SS316 internals for durability
- Dual-scale for convenience
- Standard industrial mount configuration
Typical Application
Boiler pressure monitoring, steam line gauging, compressed air systems, process equipment.
Technical Specifications
| Pressure Range | 0–16 bar / 0–250 psi |
|---|---|
| Dial Size | 100 mm (4 inch) diameter |
| Case Material | Stainless Steel (EN 837-1) |
| Tube Material | Stainless Steel Bourdon |
| Connection | 1/2" BSP bottom mount (M20x1.5) |
| Accuracy Class | 1.0 per EN 837-1 |
Specifications are indicative — exact options confirmed at the time of quotation.
